Features

Hydraulics with intelligence
Higher efficiency is ensured by larger flow, which permits wire rope reeling at a faster rate. Higher stability is achieved under simultaneous vibration-free lifting and luffing movements when shutted mode of independently controlled combined motions is used.

Two-Pump A System of Intelligent Flow Distribution
The electro-hydraulic control system achieves efficient flow distribution, is energy-efficient, ecologically benign, and responds quickly to combined motions and minor impact shocks. Accurate control: Outstanding performance inching, min. A single rope's steady speed is 1.2 meters per minute. A precise lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Integrated slewing buffer control: free swing technology, boost buffer, and sequential brakes for seamless starting and stopping.
High-performance chassis
High reliability was ensured by 200,000 cycling fatigue tests that validated the innovative structural structure.

Parameters

 Operation

Counterweight - 8.5T

Max. Lifting Capacity - 50T

Max. Boom Length - 44m

Max. Jib Length - 16m

Max. Lifting Height - 60.5m

Max. Lifting Moment - 1600kN·m

Traveling

Available Districts - LHD countries

Engine Model (Emission Standard) - DF Cummins ISLe340 40 (Euro III)

Max. Gradeability - 45%

Max. Traveling Speed - 90km/h

Wheel Formula - 8×4×4

Request for quote: +971525384269

Price: AED1568000
